Cam sensor

Goose · Oct 20, 2014

Leaking oil from seems to be the cam sensor. Trucks running bad sometimes, sometimes runs fine. It has died/stalled on me twice in the last two weeks. Pulled codes this morning: P0284, P0341, P2269, P2617 and U0306.

Truck is a 2005 with 310,xxx miles. :thumbup:

Goose · Oct 20, 2014

I guess I should have asked my question. Would the o rings fix this or should I replace the whole unit?

suprdzlduty · Oct 20, 2014

If you've never replaced it, I would go ahead and put a new one in. I would have to look at those codes but a cam sensor going out will cause those symptoms...eventually a no start.

Derek@Vision Diesel · Oct 20, 2014

As cheap as that sensor is and as much as a pain in the butt it is to get to it is a no brainer to replace it with a factory OEM unit from Ford.

Goose · Oct 25, 2014

I think that fixed my oil leak but didnt solve my running problem. Still runs like crap. I think it is a fuel issue.

Goose · Oct 26, 2014

Old sensor

suprdzlduty · Oct 26, 2014

According to the codes cyl 8 is throwing a contribution code. Might unplug it and see if it runs better just with a miss...have seen some injectors backfeed and cause more problems then actually exist.

Goose · Oct 26, 2014

It didn't throw any codes after installing the cmp. Has a definite fuel leak though. Had a small puddle just idling for a minute.

Goose · Oct 30, 2014

Found my fuel leak. Upper filter assembly.

Goose · Oct 30, 2014

Anyone know this gaskets part number?

Radioflyer · Oct 30, 2014

Just buy the blue spring kit from your dealer and it will come with a new gasket.

Goose · Nov 4, 2014

Well, that fixed my fuel leak...... Still no power. May be an oil pressure issue. ICP DC stays pegged.

On a positive not, I ordered the fuel valve kit from Sunrise Ford on Saturday morning and it was in the mail box at noon today. Awesome folks over that way.

Goose · Nov 6, 2014

Truck starts and idles fine, no issues. There are zero dtc codes. Truck has no power when accelerating. ICP duty cycle stays pegged at 94%. This is on a Scangauge that I think, has read icp/ipr% fairly accurately.

Goose · Feb 3, 2015

Now that hunting season is over its time to start on the truck. I've got it torn down to the turbo. Going to pull it when it warms up. I guess I will go ahead and install the EGR delete thats been sitting in the closet for years. :toast:

Goose · Feb 5, 2015

Ford diesel girl · Feb 6, 2015

suprdzlduty said:
If you've never replaced it, I would go ahead and put a new one in. I would have to look at those codes but a cam sensor going out will cause those symptoms...eventually a no start.

Derek@Vision Diesel said:
As cheap as that sensor is and as much as a pain in the butt it is to get to it is a no brainer to replace it with a factory OEM unit from Ford.

x2 with these two.

Had the same symptoms as you, G, a few years ago.

Goose · Feb 6, 2015

Ford diesel girl said:
x2 with these two.

Had the same symptoms as you, G, a few years ago.

Replaced the sensor a while back. Got more problems than that. I keep getting deeper into the valley and keep finding more problems. Getting the intake manifold out right now

ThreeFitty · Feb 6, 2015

sunscribed, buddy with a similar issue. hope you get this resolved

Goose · Feb 7, 2015

ThreeFitty said:
sunscribed, buddy with a similar issue. hope you get this resolved

What's his issue?

Goose · Feb 17, 2015

Help me out here. I've got the truck torn down with the intake out. What gaskets/o-rings do I need?

I can think of:

Turbo drain tube
Intake gaskets
o-ring for the oil filter housing
IPR valve

and I thats all I remember right now.
