SuperDuty - Taillight conversion

[genie144]

One of my taillights was shot out before I picked the truck up:

I had been debating on what to replace them with when I came across a good deal on a couple pairs of 2011 taillights.

The conversion is very straight forward:
Unbolt Old Lights (2 8MM hex screws)
Cut wires for reverse lights and splice in new connector (LMC 47-0432):

Bolt back in:

Pretty straight forward.

Sam



[StrokerTurbo7.3]

Looks good I want to get a set for my dads truck. His are beat up as well.

Another thing... What's going on with your mudflap? LOL



[genie144]

Looks good I want to get a set for my dads truck. His are beat up as well.

Another thing... What's going on with your mudflap? LOL

It is in the process of coming off. I didn't have a pair of pliers to grab the round head bolt that it was installed with... The will be off shortly - along with the diamond plate bed rails and tailgate cover...

Sam



[03_PSD]

Nice, you helped me find my next mod.



[sniper_101]

Put a set of these on a few months back and love them. Far brighter and modern looking, plus with the shape of them, I can see if the brake lights and running lights are working through the mirrors.



[AirFishAutomotive]

Its that big of a difference on how.bright they are compared to stockers



[Spastik monkey]

You can also use a small pick to take the plug apart and swap the terminals IIRC



[genie144]

The light difference just going to the newer style is noticeable but not huge. I have to back down my driveway and with the tinted windows it is easier. Next step for me is LED backups and if that isn't good enough - I'll wire in the aux backup lights hanging on the bumper.

Sam



[03_PSD]

I ordered a set of LED's from Retro, should be here today!!!



[F-117HWK]

Looks good. Didnt know it was that straightforward. And even from LMC brand new it looks like about $100 for the pair if I am reading that link correctly. Not too bad



[03_PSD]

you can get new tails off ebay for alot cheaper than LMC....



[F-117HWK]

you can get new tails off ebay for alot cheaper than LMC....

I know I was just using it as a ballpark as I thought they would be more expensive. I can get them at cost brand new anyways if I decide to get them :thumbsup:



[03_PSD]

Lol hook a bro up
