Installing a BD Dielse Blow Off Valve

powerstrokedkid87 · May 2, 2012

since i got the new s366 from Dozers diesel, the smaller housing is causing some turbo surge when i let off the petal. Nothing a Blow of Valve cant fix... Here is a little write up of the install. Figured i can get this done while waiting for a few items left on the interior

well got around to getting to work done on the Blow off Valve last night...here some pictures

Mocking up the mount for the BOV

drilling the 1 7/8" hole

time to weld the mount on

not bad for a Mig...

here it is all mounted up

just have some wires to connect and should be set to go

faster6.0 · May 2, 2012

Friggin sexy marky mark...

windrunner408 · May 2, 2012

Yea man looks AWESOME for sure.

HOOV3R · May 2, 2012

Looking real good.

Agjake11 · May 2, 2012

nice work

BlueWaffle · May 2, 2012

nice looking work my nugguh

powerstrokedkid87 · May 2, 2012

thanks guys...getting there its been sitting in the box too long, it will be nice to actually be able to drive the truck again rather than always tinkering

MorganY · May 2, 2012

You sir, can run a bead :thumbup:

Nic · May 2, 2012

so now that i know where this goes, what are the wires for?? is this it?

powerstrokedkid87 · May 2, 2012

Younger1993 said:
You sir, can run a bead :thumbup:

now i would love to sit here and take all the credit for the welding, but that is one of my mechanics. He has a nack for welding for sure!

powerstrokedkid87 · May 2, 2012

Nic said:
so now that i know where this goes, what are the wires for?? is this it?

This will eliminate the surge of pressure back through the turbo when you suddenly let off the accellerator. The wires are for the solenoid that attaches to the accellerator signal from the pedal. That way when the thottle is let off, the valve will open. The valve will also open at max psi, which is adjustable.

blk350on20s · May 2, 2012

Wires are for your tps. It looks for voltage changes since a diesel doesnt pull vaccum. Theres also a couple boost lines to run to the controller. Its a nice set up.

CCRICE · May 2, 2012

Good looking work man!

PGreenSVT · May 2, 2012

Am I the only one that noticed that weld didn't have any penetration for much of it? It'll probably hold for this but that wasn't a good weld IMO. Other than that it is a great job.

MorganY · May 2, 2012

PGreenSVT said:
Am I the only one that noticed that weld didn't have any penetration for much of it? It'll probably hold for this but that wasn't a good weld IMO. Other than that it is a great job.

very consistent though, something you don't see much

powerstrokedkid87 · May 3, 2012

Younger1993 said:
very consistent though, something you don't see much

im not a welder by any means, which is why he welded this for me, but i know he was concerned about burning through the pipe, so he was leary of going to hot with the weld....this should be just fine for this application.

blk350on20s · May 3, 2012

Theres plenty of penetration there. Looks just like all of my bov bungs. You forgot to paint it though lol

powerstrokedkid87 · May 3, 2012

blk350on20s said:
Theres plenty of penetration there. Looks just like all of my bov bungs. You forgot to paint it though lol

nah did not forget, the pipe has to come back out befor its all done, i will paint it then, we were just throwing it in to see what it looked like.

blk350on20s · May 3, 2012

Ya i figured. Truck looks great man. Think i might go back to my red/black combo. Looks great

powerstrokedkid87 · May 3, 2012

Thanks, its never ending.....who new a set of blown head gaskets would turn into a company starter, and this thing haha.....when my guys arent working on customer trucks, we are always tinkering with this thing!
