In a bit of a mess. Need help please.

[genuineford]

Well when I did the pressure test I didn't hear air leaking from anywhere else. I will test it again then I get the IPR back in and see what I get.

Sent from my XT897 using Tapatalk 2



[907DAVE]

Keep in mind it may take several minutes for the air to push the oil out and and audible leak to be heard.



[genuineford]

Good to know. I will try it again.

Sent from my XT897 using Tapatalk 2



[jdeeg4276]

Get a computer in it! look at the findings. My guess your stc fitting.

Sent from my DROID RAZR HD using Tapatalk 2



[jdeeg4276]

You have the cover off?!! What style stc fitting is in it?

Sent from my DROID RAZR HD using Tapatalk 2



[907DAVE]

Its an 03.



[Big Angry Hillbilly]

^^ whs.

No stc in 03 but I have seen leaks at the big o ring on pump.



[genuineford]

I want to thank all of you for your help. I was able to locate a leak for sure this morning. I found the top O-ring for #7 injector blown out. I have parts on order and should have it back together tomorrow afternoon. Dave it was your second to last post that made me really look into it more before I went off and started throwing parts at it. I will keep you updated on how it goes.



[Dave]

I want to thank all of you for your help. I was able to locate a leak for sure this morning. I found the top O-ring for #7 injector blown out. I have parts on order and should have it back together tomorrow afternoon. Dave it was your second to last post that made me really look into it more before I went off and started throwing parts at it. I will keep you updated on how it goes.

Same one that caused the no start on mine a couple months ago



[genuineford]

I got the truck all put together this afternoon and took it for a drive. I had a miss so I checked the codes and #6 was missing. When I put the injector plug in it the plug for the injector pushed back into the rocker box. I couldn't get it to pull out enough so I ended up pulling the valve cover off and getting it connected. Once that was all done we took it out for a drive and it runs better than it has in a long time and fires right up when warm. Thank you all for your help I appreciate it a lot.



[Ad8 PRODIGY]

Glad you got it fixed, Steve. Just in time, too.



[genuineford]

Yep. When we got home from the test drive it got hooked to the camper.



[genuineford]

Yep all the work was worth it.



[Mixedbreed]

my 05 had 3 injector o-rings fail, same thing would happen. but, i replaced the HPOP (twice :doh: ) before we figured it out.

i just saw this thread. sorry i couldnt help before, but these guys are pretty damn smart on here.



[drive5555]

genuineford
