superduty prerunner project

weazel

New member
Joined
Jan 31, 2012
Messages
4,862
Reaction score
0
Location
Elkview WV
So what exactly are you guys talking about when you say a 4 link will create a form of rear steer??


4 link is a suspension set up, where the axle is attached to the body via 4 bars, there is parallel 4 link, where the axle has 2 bars on each side that run parallel to each other, with that setup you need a panhard bar to control side to side movement, and there is triangulated 4 link, in this setup there are 2 bars that run straight to the outside of the axle (one per side) then there are 2 bars that go from the frame to the center of the axle, this setup will keep the axle centered with out the help of a panhard bar.

Parallel


Triangulated


Sent from my fortress of awesome

Last edited:

Cutting-Edge Diesel

Active member
Joined
Feb 10, 2012
Messages
5,738
Reaction score
0
Location
Newkirk, OK
Here are some pics that will help you understand. The axle will turn during articulation. But this thing isn't going to be a rock crawler so hopefully it will be alright.



Last edited:

mustube

New member
Joined
Mar 16, 2013
Messages
610
Reaction score
0
Location
Austin, Tx
It should be fine. How long are you making the links? Longer links will help keep the rear steer from being an issue.

Sent from my XT1058 using Tapatalk


JMart

New member
Joined
May 18, 2011
Messages
3,401
Reaction score
0
Location
DFW
Thats bad ass! That will really help. Is that part of the bender or a different tool?



How did those tires perform in the mud the other day?


Cutting-Edge Diesel

Active member
Joined
Feb 10, 2012
Messages
5,738
Reaction score
0
Location
Newkirk, OK
Added a window washer bottle. pretty much all I have done with it recently. Just been enjoying it before I tear into it again. get about 14mpg. not bad!

king stabilizers shipped today! hope to have them on when I get back from Indy




Cutting-Edge Diesel

Active member
Joined
Feb 10, 2012
Messages
5,738
Reaction score
0
Location
Newkirk, OK
It's holding up great other than the edge from me working on it.




Got my truss for the rear. Looks pretty sweet and will be perfect for my upper links



Last edited:
